TCK500 Slant Bed CNC Lathe

This series slant bed CNC lathe is new type automatic machining equipment for metal processing, suitable for batch processing of shaft and plate workpiece, with the main characters such as high efficiency, easy operating and high accuracy, this series lathe machine is mainly used for turning the internal and external cylindrical surface, conical surface and other rotating surfaces, as well as turning various type of threads etc.

立即咨询

特点

● One-piece bed adopts high strength iron to ensure rigidity and precision

● Slant bed design and linear guideways enqure process speed and accuracy

● Carriage and guide-way contact surface use Turcite B to maintain accuracy

STANDARD ACCESSORIES	OPTIONAL ACCESSORIES
Siemens controller, hydraulic turret, hydraulic chuck, hydraulic tailstock	Fanuc or other brand CNC controller, power turret, tool setting arm

产品主要技术参数

SPECIFICATIONS	Units	TCK500
Swing over bed	mm	500
Swing over cross slide	mm	380
Distance between centers	mm	500/1000/1500/2000/3000
Guideway width	°	45
Spindle bore	mm	82
Spindle speed steps	-	Stepless
Spindle speed range	rpm	35-3000
Chuck	in	10in Hydraulic chuck
Turret/tool post	-	Hydraulic turret 8position
Tool shank size	mm	25 x 25
Boring tool holder size	mm	φ40
X axis travel	mm	300
Z axis travel	mm	500/1000/1500/ 2000/3000
X axis rapid traverse	mm/min	10000 Linear guideway
Z axis rapid traverse	mm/min	15000 Linear guideway
Tailstock quill diameter	mm	φ75
Tailstock quill taper	-	MT5
Tailstock quill travel	mm	150
Main spindle motor	kw	15
Coolant pump motor	kw	0.37
Weight for 500	kg	6000
Weight for 1000	kg	6500
Weight for 1500	kg	7000
Weight for 2000	kg	7500
Weight for 3000	kg	8500
Dimension for 500	mm	4350x1800x1800
Dimension for 1000	mm	4850x1800x1800
Dimension for 1500	mm	5350x1800x1800
Dimension for 2000	mm	5850x1800x1800
Dimension for 3000	mm	6850x1800x1800
