产品型号:

X6032 Horizontal Milling Machine

This machine is a common metal cutting machine tools, spindle taper hole can be directly or through the attachment installed all cylindrical milling cutter, disc cutter, molding cutter, end milling cutter tool, suitable for machining various parts of the plane, inclined plane, grooves, holes, machinery manufacturing, mold, apparatus, instrument, automobile, motorcycle, etc. Industry ideal processing equipment.

特点

● The main components of the base, the body, the working platform, the middle slide seat and the lifting sliding seat are made of high strength material, and the stability of the machine tool long-term use is ensured by the artificial aging treatment.

● The spindle bearing of the machine tool is a tapered roller bearing. The main shaft adopts three supporting structure. The system has good rigidity, strong bearing capacity, and the main shaft adopts energy consumption brake, the braking torque is big, and the stop is fast and reliable.
● The main drive part and the work table feed part adopts the gear speed change structure, the speed regulation scope is wide, the speed change is convenient, quick.
● Table of X, y, and Z to have manual feed, mobile feed and maneuver fast forward three, different feed speed, can meet the requirements of different processing; fast feed can quickly reach the work piece, the processing position, convenient and rapid processing and shorten the processing time.
● Table x to travel up to 1000mm, and expand the scope of the machine, y, and Z to guide for the wide rectangular guide rail and X, y, Z three direction guide rail vice via ultra audio frequency induction hardening, precision grinding and scraping treatment, with forced lubrication, improve the accuracy, prolong the service life of the machine.
● Lubricating device for vertical, horizontal and vertical to the screw and guide rail are forced lubrication, reduce the tool wear, which guarantees the machine to the efficient functioning of; at the same time, cooling system by adjusting the nozzle change the size of the coolant flow, to meet the needs of different processing.
● The operating system of the machine tool is hung on the left front of the machine tool through a supporting arm, which is in accordance with the principle of human body engineering and is easy to operate. operation panel are using image symbol design, simple and intuitive.

应用案例

This machine is a common metal cutting machine tools, spindle taper hole can be directly or through the attachment installed all cylindrical milling cutter, disc cutter, molding cutter, end milling cutter tool, suitable for machining various parts of the plane, inclined plane, grooves, holes, machinery manufacturing, mold, apparatus, instrument, automobile, motorcycle, etc. Industry ideal processing equipment.

产品主要技术参数

SpecificationsUnitsX6036
Table sizemm1500x360
Table travelmm1000/320/450
T slot(number-width-pitch)mm3/18/80
Spindle taper
ISO50 7:24  ISO40 7:24
Spindle speed rangerpm60-1800(12)
Distance between spindle axis and table surfacemm0-450
Main motor powerkw4
Weightkg2400
Overall dimensionmm2220×1790×1860
